50 Design Constraints (SDC)

Interview Q&A Bank

Timing constraints — clocks, generated clocks, I/O delays, exceptions, OCV and MCMM setup

Interview Q&A Bank

This bank collects the questions that come up most in timing-constraint interviews. They are grouped by topic so you can study one area at a time. Each answer is short and uses real numbers where a number makes the idea concrete. Read the question, try to answer aloud, then check yourself against the text.

How to Use This Bank

Work through one topic group at a time rather than jumping around. Cover the answer, say yours out loud as if to an interviewer, then compare. The best answers are short and include a concrete number: "an 8.00 ns period for 125 MHz," not just "a period." If a question has a worked number, make sure you can reproduce the arithmetic, because interviewers love to change one value and ask you to redo it. Star the ones you miss and return to them the next day.

What does create_clock do? It defines a clock on a port or pin, giving the timing tool a period

and a waveform so it knows when launch and capture edges occur. Without it, the logic on that clock is not timed at all. Example: create_clock -period 4.00 defines a 250 MHz clock.

How do you convert a frequency to a period? Period in nanoseconds equals 1000 divided by

frequency in megahertz. So 200 MHz is 1000 / 200 = 5.00 ns, and 333 MHz is about 3.00 ns. The period is what create_clock takes, not the frequency.

What is clock skew? Skew is the difference in arrival time of the same clock edge at two different

flip-flops. If the launch flop sees the edge at 0.00 ns and the capture flop sees it at 0.12 ns, the skew is 0.12 ns. Skew can help or hurt a path depending on its direction.

What is clock latency? Latency is the total delay from the clock source to a flip-flop's clock pin. It

splits into source latency, from the true origin to the clock port, and network latency, from the port through the on-chip tree. Early flows model it as a single number before the tree is built.

What is the difference between an ideal and a propagated clock? An ideal clock reaches

every flip-flop at the same instant with zero skew and no tree delay. A propagated clock uses the real built-tree delays, so flops see the edge at slightly different times, producing real skew. Sign-off uses propagated clocks.

What is the default waveform of create_clock? By default the clock rises at time 0 and falls at

half the period, a 50 percent duty cycle. For a 4.00 ns period that is a rising edge at 0.00 ns and a falling edge at 2.00 ns. You can override with an explicit waveform.

How do you specify a clock that is not 50 percent duty cycle? Give an explicit waveform

listing the rise and fall times. For a 10.00 ns period that is high for 3.00 ns, you specify rise at 0.00 and fall at 3.00. This matters for paths launched or captured on the falling edge.

What is a virtual clock? A virtual clock is a clock with no source port on the chip; it exists only as

a timing reference. It is used to describe the timing of external logic for I/O delays when that clock never physically enters the chip. You reference it in set_input_delay and set_output_delay .

Generated Clocks

What is a generated clock? A clock derived from another clock by the tool, rather than declared

independently. A divide-by-two of a 5.00 ns clock becomes a 10.00 ns generated clock. It automatically tracks changes in its source, which independent clocks do not.

Why use a generated clock instead of a second create_clock? Because it stays linked to its

source. If the source period changes from 5.00 to 4.80 ns, the divided clock updates automatically. Two independent declarations drift apart the moment one is edited and the other is forgotten.

How do you make a divide-by-four clock? Use create_generated_clock with -divide_by 4

from the source clock, applied at the divider's output pin. A 2.00 ns source becomes an 8.00 ns generated clock. The tool then times that domain against the 8.00 ns period.

How do you make a multiplied clock? Use -multiply_by to model a clock faster than its

source, as from an on-chip clock generator. A 10.00 ns input multiplied by 5 yields a 2.00 ns, 500 MHz generated clock. The source is the input clock that feeds the generator.

What happens if you forget to declare a generated clock? The flip-flops on it get no clock and

go unchecked, or get the wrong clock and are checked against the wrong period. A divide-by-two path checked against the fast source period looks like a severe failure; checked against nothing looks perfect. Both are wrong.

What is a clock generated by inversion? A generated clock can be declared inverted with

respect to its source, modeling a clock that is flipped in phase. This changes which edges count as launch and capture. The period stays the same; the edges shift by half a period.

Can a generated clock have its own source latency? Yes. The generated clock inherits its

source's timing but can carry additional latency for the path through the generating logic. This models the extra delay the divider or generator adds before the new clock reaches its loads.

Port Delays

What does set_input_delay describe? It describes how long after a clock edge an input signal

becomes valid at the port, accounting for the external logic and board that drive it. For a 5.00 ns clock, an input delay of 2.40 ns means the on-chip logic has 2.60 ns left to capture.

What does set_output_delay describe? It describes how much of the clock period the external

logic downstream needs after the chip's output changes. An output delay of 1.90 ns on a 5.00 ns clock leaves 3.10 ns for the on-chip path to produce the output.

What is the difference between max and min I/O delay? Max delay models the worst-case

latest arrival and drives the setup check. Min delay models the best-case earliest arrival and drives the hold check. An input might be max 2.40 ns and min 0.60 ns, framing both the late and early edges.

Why must an I/O delay reference a clock? Because the delay is meaningless without an edge

to measure from. The referenced clock fixes when the launch or capture happens. Referencing the wrong clock measures arrival against the wrong edge and produces meaningless slack.

How do you constrain an input that has no on-chip clock to reference? Use a virtual clock

as the reference. It represents the external clock that times the source logic even though it never enters the chip. The input delay is then measured relative to that virtual clock.

What is a default input delay safety net? Setting an input delay on [all_inputs] so no port

is left unconstrained, then overriding specific ports with real numbers. This prevents the silent danger of a port with no delay being skipped entirely from analysis.

If the clock is 8.00 ns and input delay is 5.50 ns, how much time is left on-chip? 8.00 minus

5.50 equals 2.50 ns for the on-chip path from the port to the capturing flip-flop, before subtracting setup and any skew. If the on-chip logic needs more than 2.50 ns, the path fails setup.

Does set_output_delay describe on-chip or off-chip timing? Off-chip. It states how much of

the period the external receiver consumes after your output changes. The tool subtracts it from the period to find how much time your internal path has to produce the output.

Exceptions

What is a false path? A path that physically exists but is never functionally exercised, so it

should not be timed. Declaring it with set_false_path removes it from analysis. A common example is a path crossing between two truly asynchronous clocks.

When should you use set_false_path? When a path can never matter functionally: a static

configuration signal, a path between unrelated clocks handled by a synchronizer, or a path active only in a mode you do not analyze. Never use it to hide a real violation you simply cannot fix.

What is the danger of over-using false paths? Each false path removes a path from checking.

If you mark a path false that is actually real, a genuine violation goes unseen and reaches silicon. False paths must be justified by function, not convenience.

What does set_clock_groups -asynchronous do? It declares whole groups of clocks

unrelated, so the tool does not time any path crossing between groups. This is cleaner than many individual false paths when entire clock domains are independent, as on a chip bridging several interfaces.

How is set_clock_groups different from many set_false_path commands?

set_clock_groups  handles all cross-domain paths between the named groups in one statement and

stays correct as the design grows. Individual false paths must enumerate every pair and are easy to leave incomplete. Groups scale; piecemeal false paths do not.

What is the order of precedence among exceptions? Generally false path beats multicycle

path, and both beat a plain max-delay setting. A more specific exception beats a more general one.

When two exceptions overlap, the higher-priority and more specific one wins, so know which command dominates.

Can you false-path a single point-to-point path? Yes. With -from and -to you can target

one specific path while leaving the rest of those endpoints' paths checked. This is more precise than disabling a whole clock relationship and avoids hiding neighboring real paths.

Multicycle

What is a multicycle path? A path allowed more than one clock period to settle, because the

data is only sampled every few cycles. A multicycle of 3 on a 4.00 ns clock gives the path 12.00 ns for setup instead of 4.00 ns.

Why do multicycle paths exist? Because some logic legitimately does not need a result every

cycle: a slow arithmetic block whose output is used only every third cycle, or a register loaded only on certain enables. Timing them at one cycle would over-constrain them needlessly.

What is the multicycle hold trap? Relaxing only the setup multicycle leaves the default hold

check one full extra cycle after the relaxed capture edge, demanding an impossible hold. You must also relax hold, normally to N minus 1, to pull the hold check back to the right edge.

For a multicycle setup of 4, what hold do you set? A multicycle hold of 3, which is N minus 1.

This moves the hold check to one cycle after launch rather than four cycles, the correct relationship. On a 5.00 ns clock that is a hold edge at 5.00 ns, not 20.00 ns.

How much time does a multicycle setup of 2 give on a 6.00 ns clock? Two periods, 12.00

ns, for the setup check instead of one period of 6.00 ns. The path may take up to 12.00 ns minus setup and skew. The accompanying hold should be set to 1.

Can a multicycle path be applied between two different clocks? Yes, but it is trickier because

the multiplier interacts with both clocks' edges. You must reason carefully about which clock the cycle count applies to. Cross-clock multicycle paths are a frequent source of subtle errors.

What happens if you set multicycle setup but forget hold? The tool applies a hold check that

is too strict, often creating hold violations that look unfixable. Designers chasing these phantom hold failures often miss that the real fix is adding the N minus 1 hold line.

Is a multicycle path the same as a slower clock? No. A slower clock changes the timing of an

entire domain and all its checks. A multicycle path relaxes only the specific path you target, leaving the rest of the domain at full speed. It is a surgical relaxation, not a global one.

MMMC

What does MMMC stand for and mean? Multi-Mode Multi-Corner. Mode is a functional

configuration like normal versus test. Corner is a physical condition like slow-cold versus fast-hot. MMMC analyzes the design across the combinations so it works in every mode at every corner.

Why analyze multiple corners? Because silicon and environment vary. A slow, cold, low-

voltage corner stresses setup, while a fast, hot or high-voltage corner stresses hold. A chip that passes only one corner can fail in the field. You must cover the worst of each.

Which corner usually limits setup, and which limits hold? The slow corner, slow silicon at

low voltage and the temperature that maximizes delay, usually limits setup because paths are slowest. The fast corner, fast silicon, usually limits hold because data races through and can arrive too early. You check both.

What is a mode in MMMC? A functional configuration of the chip with its own constraints, such

as a normal operating mode and a scan-test mode. Each mode may use different clocks, different case-analysis settings, and different exceptions, so each needs its own constraint view.

Why combine modes and corners instead of checking them separately by hand? Because

the number of combinations grows quickly and a flow that handles them together guarantees none is forgotten. Checking by hand invites missing a mode-corner pair where the chip actually fails. MMMC makes the coverage systematic.

Can different modes share constraints? Yes, and they should. Common constraints like the

main clock live in a shared file every mode reads, while mode-specific items like case analysis live in per-mode files. This keeps the shared parts consistent and reduces duplication across modes.

Constraint Management

What is a golden SDC? The single trusted constraint set that every flow step reads, so

synthesis, placement, routing, and timing all judge the design identically. One edit propagates everywhere, and the chip you tape out matches the chip you analyzed.

How do you split constraints between block and top level? Block constraints cover one

block's pins, internal paths, and budgeted I/O delays. Top constraints define clocks at their true source, use real I/O delays, and add cross-block exceptions. The block's estimates must be reconciled with top-level reality.

What does it mean to budget block I/O delays? To split a clock period that a cross-block path

must fit into shares: source block internal, wire, destination block internal. Each share becomes an input or output delay, and all shares must sum to the full period. For 2.50 ns you might use 0.90, 0.40, and 1.20.

Why keep constraints in version control? Because constraints directly determine sign-off

results, and the commit history shows which edit caused a timing change between runs. Without history you cannot tell whether a regression came from the design or from a quietly changed constraint number.

How do you check a constraint set is complete? Report all clocks and compare to the design,

report unconstrained ports and paths, and confirm every generated clock is declared. A clean timing report on an incomplete constraint set is the real hazard, so coverage is verified before reading slack.

What is the single most dangerous constraint mistake? An unconstrained path, because it is

never checked and so passes silently while it may be far too slow. A failing path is honest and gets fixed; a path that was never analyzed walks straight into silicon as hidden risk.
